Weekly RVtools report - add colour

I find many post on how to add colour to reports, but I can't really wrap my head around it on how I can do it in my dataset.
Hopefully someone can point me in the right directions.

I have made a weekly report that adds many rvtools reports into the dataset.
The table ends up something like this.



SourceServerRamGBDate
rvtools-week1Server187/1-23
rvtools-week2Server1814/1-23
rvtools-week3Server11221/1-23


How can I add colour to my report. If RamGB is higher from last week, I would like the number to show up as green. If it is lower, red.





1 ACCEPTED SOLUTION
Anonymous
Not applicable

Hi  @Raggsokk ,



Here are the steps you can follow:

1. Create measure.



Flag =
var _select=
SELECTEDVALUE('Table'[Date])
var _current=
SUMX(
    FILTER(ALL('Table'),
    WEEKNUM(_select,2)=WEEKNUM('Table'[Date],2)&&'Table'[Server]=MAX('Table'[Server])),[RamGB])
var _last=
SUMX(
    FILTER(ALL('Table'),
    WEEKNUM(_select,2)-1=WEEKNUM('Table'[Date],2)&&'Table'[Server]=MAX('Table'[Server])),[RamGB])
return
SWITCH(
    TRUE(),
        _last>_current,"red",
        _last=_current,"yellow",
        "blue")



2. Conditional formatting – Background color.



3. Result:




Best Regards,

Liu Yang

If this post helps, then please consider Accept it as the solution to help the other members find it more quickly

View solution in original post

3 REPLIES 3
Anonymous
Not applicable

Hi  @Raggsokk ,



Here are the steps you can follow:

1. Create measure.



Flag =
var _select=
SELECTEDVALUE('Table'[Date])
var _current=
SUMX(
    FILTER(ALL('Table'),
    WEEKNUM(_select,2)=WEEKNUM('Table'[Date],2)&&'Table'[Server]=MAX('Table'[Server])),[RamGB])
var _last=
SUMX(
    FILTER(ALL('Table'),
    WEEKNUM(_select,2)-1=WEEKNUM('Table'[Date],2)&&'Table'[Server]=MAX('Table'[Server])),[RamGB])
return
SWITCH(
    TRUE(),
        _last>_current,"red",
        _last=_current,"yellow",
        "blue")



2. Conditional formatting – Background color.



3. Result:




Best Regards,

Liu Yang

If this post helps, then please consider Accept it as the solution to help the other members find it more quickly

Hi, Are you using the fabric to import the data from rvtools? or is there a template or something?



Care to share?



Thank you

We have a PowerShell script that runs on a schedule each week.

I then merge all files in the same folder in powerbi.
